NEWEST FEATURES

FEATURE COMPARISON

Product Version Student Standard Pro
Feature
Open/run demo models Yes Yes Yes
Create/edit models Yes Yes Yes
CAD Windows interface Yes Yes Yes
Integrated help system Yes Yes Yes
Geometry & Materials
Number of regions 10 unlimited unlimited
Number of materials 3 unlimited unlimited
Finite element integration 800 unlimited unlimited
Import regions from AutoCAD™ DXF files   Yes Yes
Pinch out surfaces (3D) Yes Yes Yes
CAD functionality Yes Yes Yes
Licensed for engineering consulting use   Yes Yes
Dimensions
1D Simulation Yes Yes Yes
2D Simulation Yes Yes Yes
3D Simulation Yes Yes Yes
Analysis Types
Fully coupled with SVFlux™     Yes
Diffusion Yes Yes Yes
Advective-Dispersion Yes Yes Yes
Adsorption Yes Yes Yes
Radioactive Decay Yes Yes Yes
Density Dependent with SVFlux™   Yes Yes
Add-in function (user defined)   Yes Yes
Anisotropic   Yes Yes
Saturated/Unsaturated Yes Yes Yes
Density dependant flow     Yes
Particle tracking Yes Yes Yes
Mesh
Fully-automatic generation Yes Yes Yes
Fully automatic mesh refinement Yes Yes Yes
Mesh refinement following contaminant front Yes Yes Yes
Equation Solvers
Galerkin finite element method   Yes Yes
Input / Export Data Sets
From seepage (SVFlux™)   Yes Yes
To seepage (SVFlux™)   Yes Yes
*Student editions are limited to 800 nodes in 2D and 1600 nodes in 3D.

DETAILED FEATURES

  • Multiple types of analysis available including steady-state and transient, with both saturated and unsaturated material models. Create models in 1D, 2D, 3D, plan, or axisymmetric views
  • Analyze advection, diffusion, absorption and biological or radioactive decay
  • Fully automatic mesh generation: mesh generation may be limited by a maximum number of nodes or by a maximum specified error.

    View examples of three-dimensional meshing in action
  • Fully automatic mesh refinement

    Mesh refinement is based on the relative error of the governing equation and therefore automatically locates critical zones. Mesh refinement may be specified to follow any particular variable in the problem. In a transient analysis a different mesh is generated for each time step.

    Read more about adaptive grid refinement in research published by Mansell, 2002
  • Finite element analysis by the Galerkin method - the solver uses advanced features such as preconditioning of the convergence matrix as well as staging and automatic mesh refinement to achieve solutions with greater stability than any other software currently available
  • Model advection, diffusion, absorption and decay in saturated and unsaturated soil conditions
  • Customizable solutions through a modifiable governing partial differential equation
  • Input flux or climate boundary conditions as constants or free-form equations
  • Initial conditions may be imported from a previous analysis; use any variable from a previous analysis as an initial condition for the next analysis
  • Anisotropic analysis at any angle in two or three dimensions
  • Perched or multiple water tables may be incorporated
  • Contour or vector plots of concentration are possible
  • Solver runs on Red Hat Linux or Windows, with support for hyper-threading and multiple processors

MODEL DESIGN FEATURES

  • CAD style entry of geometry based on AutoCAD™
  • Grid, snapping, and object snapping features available
  • Zooming, panning features available
  • Model built as stacked surfaces; Each surface may be imported from Surfer or any XYZ data text file
  • Models stored in XML format for speed and easy data transfer
  • Each surface may have multiple regions defined - Regions are extruded between the surfaces on which they are placed
  • Automatic pinching out of intersecting soil layers or grids. Overlapping grids can also be handled by specifying which grid is the domainant grid. They can also be specified to allow a minimum thickness between grids.
  • Import AutoCAD™ .dxf geometry and incorporate it directly into the model - node points are automatically aligned with line segment end points
  • Graphically assigned boundary conditions
  • Free form equations or tabled concentration data may be input as boundary conditions (in addition to standard head or flux boundary conditions). Head or flux boundary conditions may be specified as contants or free-form equations. Free form equations may be specified as a function of position or time (i.e., h=30+exp(t)*2.5)
  • Problems may be entered in Metric or Imperial units
  • Initial water table may be graphically drawn on the problem or imported from a previous analysis
  • Problem geometry may be imported from existing problems
  • Colors or patterns of soil regions may be specified
  • Manual entry of region coordinate points
  • Lines (extruded into walls) may be added to model to force mesh refinement along a linear object
  • Internal boundary conditions may be set or node density specified along internal line objects
  • Sketch text or lines may be added to the model design
  • Graphical model design may be exported as a WMF or DXF file and/or printed
  • Bitmap or DXF geometry may be imported and layered behind model geometry to simplify model creation

OUTPUT FEATURES

  • Color visualization of the result mesh is available via our powerful AcuMesh™ visualization software
  • Transparency allows visualization of three-dimensional internal mesh and/or isosurfaces
  • Cutaways allow user to view internal sections of the model
  • Color contour plots of any problem variable may be placed on any face of the model; custom color shadings may be specified
  • Color contour plots of all relevant variables
  • Isosurfaces may be plotted for three-dimensional models
  • Two- or three-dimensional vector plots of concentration components are available
  • Plots may be zoomed to isolate any region of interest
  • Cross plots of stress or deformation components are available
  • Plots of Mohr's circle at any finite element node are available
  • Volume integrals may be computed over the entire problem or any particular region of interest
  • Mesh plots track mesh refinement
  • Plots of value versus time may be generated at any coordinate for all relevant variables
  • Surface plots of any two-dimensional variable over the problem region may be produced
  • Overlaying of plots may be performed - for example, vectors may be shown in Region 1 while contours of head may be shown in Region 2
  • Text and line art may be added to output
  • Graphical output may be exported to WMF, DXF, JPG, or BMP formats
  • Animation of any transient results
